Name: STURDX Essential Series™ 12U IP66 Weatherproof Stainless Steel Outdoor Network Cabinet | 24" × 18" (600 × 450 mm) | 19-Inch Rack Enclosure
Brand: STURDX
SKU: STX-ES-12U450-SS
Price: 2750.00 USD
Availability: InStock

{"id":10428462039319,"title":"STURDX Essential Series™ 12U IP66 Weatherproof Stainless Steel Outdoor Network Cabinet | 24\" × 18\" (600 × 450 mm) | 19-Inch Rack Enclosure","handle":"12u600-outdoor-network-cabinet-enclosure-ip66-rated-weatherproof-for-telecom-fiber-and-server-equipment-stainless-steel-with-air-conditioning-600mm-x-450mm-24-x-18-floor-pole-and-wall-mount-stv-hc-12u600","description":"\u003ch2\u003eProduct Overview\u003c\/h2\u003e\n\u003cp\u003eThe \u003cstrong\u003eSTURDX Essential Series™ 12U IP66 Weatherproof Stainless Steel Outdoor Network Cabinet (24\" × 18\" \/ 600 × 450 mm)\u003c\/strong\u003e is engineered for outdoor installations where \u003cstrong\u003ecompact dimensions, superior corrosion resistance, and flexible mounting options\u003c\/strong\u003e are essential. Designed for edge networking, wireless communications, industrial automation, surveillance systems, and mission-critical infrastructure, the \u003cstrong\u003e12U\u003c\/strong\u003e platform provides dependable environmental protection while fitting locations where installation space is limited.\u003c\/p\u003e\n\u003cp\u003eManufactured from \u003cstrong\u003e304 stainless steel\u003c\/strong\u003e, the enclosure is designed to withstand salt spray, coastal humidity, chemical vapors, washdown environments, and corrosive industrial atmospheres. It is particularly well suited for \u003cstrong\u003emarine vessels, offshore platforms, ports, shipyards, marinas, coastal telecommunications, wastewater treatment facilities, food processing plants, pharmaceutical manufacturing, and chemical processing industries\u003c\/strong\u003e. For the most demanding offshore and corrosive applications, \u003cstrong\u003e316 stainless steel\u003c\/strong\u003e construction is available upon request.\u003c\/p\u003e\n\u003cp\u003eIts compact \u003cstrong\u003e24-inch × 18-inch (600 × 450 mm)\u003c\/strong\u003e footprint provides sufficient space for networking switches, industrial Ethernet devices, fiber optic termination panels, communication gateways, SCADA equipment, and compact power distribution systems while remaining easy to install and maintain.\u003c\/p\u003e\n\u003cp\u003eThe cabinet features a \u003cstrong\u003esingle lockable front door\u003c\/strong\u003e and includes a \u003cstrong\u003eheavy-duty wall mounting bracket\u003c\/strong\u003e and \u003cstrong\u003efloor plinth\u003c\/strong\u003e as standard equipment. For communication poles, utility poles, traffic systems, and wireless infrastructure, an \u003cstrong\u003eoptional heavy-duty pole mounting bracket\u003c\/strong\u003e is available.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch1\u003eTechnical Specifications\u003c\/h1\u003e\n\u003ctable\u003e\n\u003cthead\u003e\n\u003ctr\u003e\n\u003cth\u003eSpecification\u003c\/th\u003e\n\u003cth\u003eValue\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003c\/thead\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eSeries\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003eSTURDX Essential Series™\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eSKU\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cstrong\u003eSTX-ES-12U450-SS\u003c\/strong\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRack Height\u003c\/td\u003e\n\u003ctd\u003e12U\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRack Standard\u003c\/td\u003e\n\u003ctd\u003e19-inch EIA-310\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eExternal Dimensions\u003c\/td\u003e\n\u003ctd\u003e23.6\" × 17.7\" (600 × 450 mm)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eMaterial\u003c\/td\u003e\n\u003ctd\u003e304 Stainless Steel \u003cem\u003e(316 Stainless Steel Available Upon Request)\u003c\/em\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConstruction\u003c\/td\u003e\n\u003ctd\u003eSingle-Wall Construction\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eProtection Rating\u003c\/td\u003e\n\u003ctd\u003eIP66\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eNEMA\u003c\/td\u003e\n\u003ctd\u003eSuitable for NEMA 4X Applications\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCooling\u003c\/td\u003e\n\u003ctd\u003eFan Ready\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eMounting Rails\u003c\/td\u003e\n\u003ctd\u003eFour Adjustable Rails Included\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eDIN Rail\u003c\/td\u003e\n\u003ctd\u003eIncluded\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCable Glands\u003c\/td\u003e\n\u003ctd\u003eIP68 Rated Included \u003cem\u003e(316 Stainless Steel Available Upon Request)\u003c\/em\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCable Entry\u003c\/td\u003e\n\u003ctd\u003eBottom Knockouts\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eDoors\u003c\/td\u003e\n\u003ctd\u003eLockable Front Door\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eWall Mount\u003c\/td\u003e\n\u003ctd\u003eHeavy-Duty Wall Mount Bracket Included\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003ePole Mount\u003c\/td\u003e\n\u003ctd\u003eOptional Heavy-Duty Pole Mount Bracket Available\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003ePlinth\u003c\/td\u003e\n\u003ctd\u003eIncluded\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eGrounding\u003c\/td\u003e\n\u003ctd\u003eIncluded\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003chr\u003e\n\u003ch1\u003eStandard Features\u003c\/h1\u003e\n\u003cp\u003eEvery STURDX Essential Series™ cabinet includes:\u003c\/p\u003e\n\u003cul\u003e\n\u003cli\u003e\n\u003cp\u003e304 stainless steel construction\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eSingle-wall enclosure\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eIP66 weatherproof protection\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eSuitable for NEMA 4X applications\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eFan-ready design\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eFour adjustable 19-inch rack rails\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eDIN rail included\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eIP68 cable glands included\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eBottom cable entry knockouts\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eLockable front door\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eHeavy-duty wall mounting bracket included\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eOptional heavy-duty pole mounting bracket\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eFloor plinth included\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eHeavy-duty polyurethane door gasket\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eIntegrated grounding system\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eStainless steel hinges, latches, and external hardware\u003c\/p\u003e\n\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003chr\u003e\n\u003ch1\u003eDesigned for Marine and Corrosive Environments\u003c\/h1\u003e\n\u003cp\u003eThe \u003cstrong\u003e24\" × 18\" (600 × 450 mm)\u003c\/strong\u003e enclosure is specifically designed for installations where corrosion resistance is just as important as equipment protection. Its compact footprint allows deployment on buildings, communication structures, utility facilities, ships, ports, and industrial sites while protecting sensitive electronics from moisture, salt air, and aggressive environmental conditions.\u003c\/p\u003e\n\u003cp\u003eThe cabinet provides ample room for compact networking equipment, industrial controllers, fiber distribution hardware, and communication devices while maintaining convenient front-only access for simplified servicing in confined installation areas.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch1\u003eProduct Description\u003c\/h1\u003e\n\u003cp\u003eThe \u003cstrong\u003eSTURDX Essential Series™ 12U Stainless Steel Outdoor Network Cabinet\u003c\/strong\u003e delivers premium environmental protection for networking, telecommunications, industrial automation, electrical distribution, and communication equipment operating in harsh outdoor and corrosive environments.\u003c\/p\u003e\n\u003cp\u003eIts \u003cstrong\u003e24\" × 18\" (600 × 450 mm)\u003c\/strong\u003e footprint, \u003cstrong\u003esingle-wall stainless steel construction\u003c\/strong\u003e, included wall mounting bracket, integrated floor plinth, and \u003cstrong\u003eIP66 weatherproof protection\u003c\/strong\u003e make it an ideal solution for marine, offshore, coastal, industrial, utility, and mission-critical outdoor infrastructure.\u003c\/p\u003e\n\u003cp\u003eFor applications requiring active enclosure cooling, STURDX also offers the \u003cstrong\u003eClimate Series™\u003c\/strong\u003e, compatible with \u003cstrong\u003e300W (≈1,000 BTU\/hr) AC or DC enclosure air conditioners\u003c\/strong\u003e.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch1\u003eTypical Applications\u003c\/h1\u003e\n\u003cul\u003e\n\u003cli\u003e\n\u003cp\u003eMarine Vessels\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eOffshore Platforms\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003ePorts \u0026amp; Harbors\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eMarinas\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eCoastal Telecommunications\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eHarbor Communication Systems\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eWireless Communication Equipment\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eFiber Distribution\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eCCTV \u0026amp; Surveillance\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eSmart City Infrastructure\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eUtility Monitoring\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eIndustrial Automation\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eSCADA Systems\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eRemote Monitoring\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eFood Processing Facilities\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eChemical Processing Plants\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003ePharmaceutical Manufacturing\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eRenewable Energy\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eIndustrial Ethernet\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eMission-Critical Communications\u003c\/p\u003e\n\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003chr\u003e\n\u003ch1\u003eFrequently Asked Questions\u003c\/h1\u003e\n\u003ch3\u003eWhy choose a 12U stainless steel outdoor cabinet?\u003c\/h3\u003e\n\u003cp\u003eA \u003cstrong\u003e12U\u003c\/strong\u003e enclosure offers compact rack capacity while stainless steel construction provides outstanding resistance to salt air, humidity, chemicals, and corrosive industrial environments, helping extend equipment and enclosure service life.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eIs this enclosure suitable for marine and offshore installations?\u003c\/h3\u003e\n\u003cp\u003eYes. The enclosure is ideal for \u003cstrong\u003eships, offshore platforms, ports, marinas, coastal communication systems, and other salt-air environments\u003c\/strong\u003e. For maximum corrosion resistance, \u003cstrong\u003e316 stainless steel\u003c\/strong\u003e is available upon request.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eDoes this cabinet include a rear door?\u003c\/h3\u003e\n\u003cp\u003eNo. The standard configuration includes a \u003cstrong\u003esingle lockable front door\u003c\/strong\u003e, maximizing usable interior space and simplifying installation.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eCan this cabinet be wall mounted?\u003c\/h3\u003e\n\u003cp\u003eYes. Every cabinet includes a \u003cstrong\u003eheavy-duty wall mounting bracket\u003c\/strong\u003e as standard.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eIs pole mounting available?\u003c\/h3\u003e\n\u003cp\u003eYes. An \u003cstrong\u003eoptional heavy-duty pole mounting bracket\u003c\/strong\u003e is available for communication poles, utility poles, lighting poles, roadside infrastructure, and wireless communication installations.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eIs a floor plinth included?\u003c\/h3\u003e\n\u003cp\u003eYes. Every \u003cstrong\u003e12U Essential Series™ 600 × 450 mm\u003c\/strong\u003e cabinet includes a \u003cstrong\u003efloor plinth\u003c\/strong\u003e as standard.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eCan optional fan kits be installed?\u003c\/h3\u003e\n\u003cp\u003eYes. The Essential Series™ is \u003cstrong\u003efan-ready\u003c\/strong\u003e and supports optional filtered fan ventilation whenever additional airflow is required.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eCan STURDX customize this enclosure?\u003c\/h3\u003e\n\u003cp\u003eAbsolutely. STURDX offers custom dimensions, \u003cstrong\u003e304 or 316 stainless steel construction\u003c\/strong\u003e, OEM branding, cable entry modifications, electrical integration, gland plates, rack accessories, wall or pole mounting solutions, and project-specific configurations for marine, industrial, telecommunications, utility, transportation, and critical infrastructure applications.\u003c\/p\u003e","published_at":"2026-09-02T17:23:04-05:00","created_at":"2026-07-20T04:37:22-05:00","vendor":"STURDX ","type":"Floor Standing Outdoor Network Cabinets","tags":["19\" Equipment Mounting","19\" Rack Systems","All-Weather Network Cabinet","Custom-Made Outdoor Cabinets","Dust and Water Protection","Environmental Protection Cabinet","Environments","Equipment Protection","Exterior Network Rack Enclosure","Galvanized Steel Construction","IP54 Fan and Filter Compatibility","IP55 Rated Cabinet","IP55 Rated Network Cabinet","Network Cabinet for Harsh","Network Rack for Outdoor Use","Outdoor Data Center Cabinet","Outdoor Electronics Enclosure","Outdoor IT Cabinet","Outdoor IT Rack Cabinet","Outdoor Network Cabinet","Outdoor Network Cabinet Solutions","Outdoor Network Equipment Cabinet","Outdoor Network Equipment Protection","Outdoor Network Server Cabinet","Outdoor Network Storage Cabinet","Outdoor Rack Cabinet","Outdoor Server Cabinet","Pole or Wall Mountable Cabinet","Rack Cabinet Solution","Ral 7035 Epoxy Coating","Vatpan Rack Cabinet","Waterproof Network Rack Cabinet","Watertight Seal","Weatherproof Network Enclosure"],"price":275000,"price_min":275000,"price_max":275000,"available":true,"price_varies":false,"compare_at_price":490000,"compare_at_price_min":490000,"compare_at_price_max":490000,"compare_at_price_varies":false,"variants":[{"id":54169388974359,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"STX-ES-12U450-SS","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"STURDX Essential Series™ 12U IP66 Weatherproof Stainless Steel Outdoor Network Cabinet | 24\" × 18\" (600 × 450 mm) | 19-Inch Rack Enclosure","public_title":null,"options":["Default Title"],"price":275000,"weight":0,"compare_at_price":490000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/www.serverrackcabinets.com\/cdn\/shop\/files\/sturdx-outdoor-stainless-cabinet-closed-front-locking-handle.webp?v=1786697376","\/\/www.serverrackcabinets.com\/cdn\/shop\/files\/sturdx-seven-u-cabinet-closed-front-angle-locking-handle.jpg?v=1786697689","\/\/www.serverrackcabinets.com\/cdn\/shop\/files\/sturdx-nine-u-cabinet-open-door-interior-rack-rails.jpg?v=1786697438"],"featured_image":"\/\/www.serverrackcabinets.com\/cdn\/shop\/files\/sturdx-outdoor-stainless-cabinet-closed-front-locking-handle.webp?v=1786697376","options":["Title"],"media":[{"alt":"STURDX outdoor stainless cabinet closed at the front with a locking handle","id":44592069804311,"position":1,"preview_image":{"aspect_ratio":1.253,"height":479,"width":600,"src":"\/\/www.serverrackcabinets.com\/cdn\/shop\/files\/sturdx-outdoor-stainless-cabinet-closed-front-locking-handle.webp?v=1786697376"},"aspect_ratio":1.253,"height":479,"media_type":"image","src":"\/\/www.serverrackcabinets.com\/cdn\/shop\/files\/sturdx-outdoor-stainless-cabinet-closed-front-locking-handle.webp?v=1786697376","width":600},{"alt":"STURDX 7U cabinet closed at a front angle with its locking handle showing","id":44284813345047,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1024,"width":1024,"src":"\/\/www.serverrackcabinets.com\/cdn\/shop\/files\/sturdx-seven-u-cabinet-closed-front-angle-locking-handle.jpg?v=1786697689"},"aspect_ratio":1.0,"height":1024,"media_type":"image","src":"\/\/www.serverrackcabinets.com\/cdn\/shop\/files\/sturdx-seven-u-cabinet-closed-front-angle-locking-handle.jpg?v=1786697689","width":1024},{"alt":"STURDX 9U cabinet open door showing the interior 9U rack rails in detail","id":44284969189655,"position":3,"preview_image":{"aspect_ratio":1.334,"height":896,"width":1195,"src":"\/\/www.serverrackcabinets.com\/cdn\/shop\/files\/sturdx-nine-u-cabinet-open-door-interior-rack-rails.jpg?v=1786697438"},"aspect_ratio":1.334,"height":896,"media_type":"image","src":"\/\/www.serverrackcabinets.com\/cdn\/shop\/files\/sturdx-nine-u-cabinet-open-door-interior-rack-rails.jpg?v=1786697438","width":1195}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch2\u003eProduct Overview\u003c\/h2\u003e\n\u003cp\u003eThe \u003cstrong\u003eSTURDX Essential Series™ 12U IP66 Weatherproof Stainless Steel Outdoor Network Cabinet (24\" × 18\" \/ 600 × 450 mm)\u003c\/strong\u003e is engineered for outdoor installations where \u003cstrong\u003ecompact dimensions, superior corrosion resistance, and flexible mounting options\u003c\/strong\u003e are essential. Designed for edge networking, wireless communications, industrial automation, surveillance systems, and mission-critical infrastructure, the \u003cstrong\u003e12U\u003c\/strong\u003e platform provides dependable environmental protection while fitting locations where installation space is limited.\u003c\/p\u003e\n\u003cp\u003eManufactured from \u003cstrong\u003e304 stainless steel\u003c\/strong\u003e, the enclosure is designed to withstand salt spray, coastal humidity, chemical vapors, washdown environments, and corrosive industrial atmospheres. It is particularly well suited for \u003cstrong\u003emarine vessels, offshore platforms, ports, shipyards, marinas, coastal telecommunications, wastewater treatment facilities, food processing plants, pharmaceutical manufacturing, and chemical processing industries\u003c\/strong\u003e. For the most demanding offshore and corrosive applications, \u003cstrong\u003e316 stainless steel\u003c\/strong\u003e construction is available upon request.\u003c\/p\u003e\n\u003cp\u003eIts compact \u003cstrong\u003e24-inch × 18-inch (600 × 450 mm)\u003c\/strong\u003e footprint provides sufficient space for networking switches, industrial Ethernet devices, fiber optic termination panels, communication gateways, SCADA equipment, and compact power distribution systems while remaining easy to install and maintain.\u003c\/p\u003e\n\u003cp\u003eThe cabinet features a \u003cstrong\u003esingle lockable front door\u003c\/strong\u003e and includes a \u003cstrong\u003eheavy-duty wall mounting bracket\u003c\/strong\u003e and \u003cstrong\u003efloor plinth\u003c\/strong\u003e as standard equipment. For communication poles, utility poles, traffic systems, and wireless infrastructure, an \u003cstrong\u003eoptional heavy-duty pole mounting bracket\u003c\/strong\u003e is available.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch1\u003eTechnical Specifications\u003c\/h1\u003e\n\u003ctable\u003e\n\u003cthead\u003e\n\u003ctr\u003e\n\u003cth\u003eSpecification\u003c\/th\u003e\n\u003cth\u003eValue\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003c\/thead\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eSeries\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003eSTURDX Essential Series™\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003eSKU\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cstrong\u003eSTX-ES-12U450-SS\u003c\/strong\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRack Height\u003c\/td\u003e\n\u003ctd\u003e12U\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRack Standard\u003c\/td\u003e\n\u003ctd\u003e19-inch EIA-310\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eExternal Dimensions\u003c\/td\u003e\n\u003ctd\u003e23.6\" × 17.7\" (600 × 450 mm)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eMaterial\u003c\/td\u003e\n\u003ctd\u003e304 Stainless Steel \u003cem\u003e(316 Stainless Steel Available Upon Request)\u003c\/em\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConstruction\u003c\/td\u003e\n\u003ctd\u003eSingle-Wall Construction\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eProtection Rating\u003c\/td\u003e\n\u003ctd\u003eIP66\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eNEMA\u003c\/td\u003e\n\u003ctd\u003eSuitable for NEMA 4X Applications\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCooling\u003c\/td\u003e\n\u003ctd\u003eFan Ready\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eMounting Rails\u003c\/td\u003e\n\u003ctd\u003eFour Adjustable Rails Included\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eDIN Rail\u003c\/td\u003e\n\u003ctd\u003eIncluded\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCable Glands\u003c\/td\u003e\n\u003ctd\u003eIP68 Rated Included \u003cem\u003e(316 Stainless Steel Available Upon Request)\u003c\/em\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCable Entry\u003c\/td\u003e\n\u003ctd\u003eBottom Knockouts\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eDoors\u003c\/td\u003e\n\u003ctd\u003eLockable Front Door\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eWall Mount\u003c\/td\u003e\n\u003ctd\u003eHeavy-Duty Wall Mount Bracket Included\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003ePole Mount\u003c\/td\u003e\n\u003ctd\u003eOptional Heavy-Duty Pole Mount Bracket Available\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003ePlinth\u003c\/td\u003e\n\u003ctd\u003eIncluded\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eGrounding\u003c\/td\u003e\n\u003ctd\u003eIncluded\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003chr\u003e\n\u003ch1\u003eStandard Features\u003c\/h1\u003e\n\u003cp\u003eEvery STURDX Essential Series™ cabinet includes:\u003c\/p\u003e\n\u003cul\u003e\n\u003cli\u003e\n\u003cp\u003e304 stainless steel construction\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eSingle-wall enclosure\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eIP66 weatherproof protection\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eSuitable for NEMA 4X applications\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eFan-ready design\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eFour adjustable 19-inch rack rails\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eDIN rail included\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eIP68 cable glands included\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eBottom cable entry knockouts\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eLockable front door\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eHeavy-duty wall mounting bracket included\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eOptional heavy-duty pole mounting bracket\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eFloor plinth included\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eHeavy-duty polyurethane door gasket\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eIntegrated grounding system\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eStainless steel hinges, latches, and external hardware\u003c\/p\u003e\n\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003chr\u003e\n\u003ch1\u003eDesigned for Marine and Corrosive Environments\u003c\/h1\u003e\n\u003cp\u003eThe \u003cstrong\u003e24\" × 18\" (600 × 450 mm)\u003c\/strong\u003e enclosure is specifically designed for installations where corrosion resistance is just as important as equipment protection. Its compact footprint allows deployment on buildings, communication structures, utility facilities, ships, ports, and industrial sites while protecting sensitive electronics from moisture, salt air, and aggressive environmental conditions.\u003c\/p\u003e\n\u003cp\u003eThe cabinet provides ample room for compact networking equipment, industrial controllers, fiber distribution hardware, and communication devices while maintaining convenient front-only access for simplified servicing in confined installation areas.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch1\u003eProduct Description\u003c\/h1\u003e\n\u003cp\u003eThe \u003cstrong\u003eSTURDX Essential Series™ 12U Stainless Steel Outdoor Network Cabinet\u003c\/strong\u003e delivers premium environmental protection for networking, telecommunications, industrial automation, electrical distribution, and communication equipment operating in harsh outdoor and corrosive environments.\u003c\/p\u003e\n\u003cp\u003eIts \u003cstrong\u003e24\" × 18\" (600 × 450 mm)\u003c\/strong\u003e footprint, \u003cstrong\u003esingle-wall stainless steel construction\u003c\/strong\u003e, included wall mounting bracket, integrated floor plinth, and \u003cstrong\u003eIP66 weatherproof protection\u003c\/strong\u003e make it an ideal solution for marine, offshore, coastal, industrial, utility, and mission-critical outdoor infrastructure.\u003c\/p\u003e\n\u003cp\u003eFor applications requiring active enclosure cooling, STURDX also offers the \u003cstrong\u003eClimate Series™\u003c\/strong\u003e, compatible with \u003cstrong\u003e300W (≈1,000 BTU\/hr) AC or DC enclosure air conditioners\u003c\/strong\u003e.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch1\u003eTypical Applications\u003c\/h1\u003e\n\u003cul\u003e\n\u003cli\u003e\n\u003cp\u003eMarine Vessels\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eOffshore Platforms\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003ePorts \u0026amp; Harbors\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eMarinas\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eCoastal Telecommunications\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eHarbor Communication Systems\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eWireless Communication Equipment\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eFiber Distribution\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eCCTV \u0026amp; Surveillance\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eSmart City Infrastructure\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eUtility Monitoring\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eIndustrial Automation\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eSCADA Systems\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eRemote Monitoring\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eFood Processing Facilities\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eChemical Processing Plants\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003ePharmaceutical Manufacturing\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eRenewable Energy\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eIndustrial Ethernet\u003c\/p\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003cp\u003eMission-Critical Communications\u003c\/p\u003e\n\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003chr\u003e\n\u003ch1\u003eFrequently Asked Questions\u003c\/h1\u003e\n\u003ch3\u003eWhy choose a 12U stainless steel outdoor cabinet?\u003c\/h3\u003e\n\u003cp\u003eA \u003cstrong\u003e12U\u003c\/strong\u003e enclosure offers compact rack capacity while stainless steel construction provides outstanding resistance to salt air, humidity, chemicals, and corrosive industrial environments, helping extend equipment and enclosure service life.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eIs this enclosure suitable for marine and offshore installations?\u003c\/h3\u003e\n\u003cp\u003eYes. The enclosure is ideal for \u003cstrong\u003eships, offshore platforms, ports, marinas, coastal communication systems, and other salt-air environments\u003c\/strong\u003e. For maximum corrosion resistance, \u003cstrong\u003e316 stainless steel\u003c\/strong\u003e is available upon request.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eDoes this cabinet include a rear door?\u003c\/h3\u003e\n\u003cp\u003eNo. The standard configuration includes a \u003cstrong\u003esingle lockable front door\u003c\/strong\u003e, maximizing usable interior space and simplifying installation.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eCan this cabinet be wall mounted?\u003c\/h3\u003e\n\u003cp\u003eYes. Every cabinet includes a \u003cstrong\u003eheavy-duty wall mounting bracket\u003c\/strong\u003e as standard.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eIs pole mounting available?\u003c\/h3\u003e\n\u003cp\u003eYes. An \u003cstrong\u003eoptional heavy-duty pole mounting bracket\u003c\/strong\u003e is available for communication poles, utility poles, lighting poles, roadside infrastructure, and wireless communication installations.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eIs a floor plinth included?\u003c\/h3\u003e\n\u003cp\u003eYes. Every \u003cstrong\u003e12U Essential Series™ 600 × 450 mm\u003c\/strong\u003e cabinet includes a \u003cstrong\u003efloor plinth\u003c\/strong\u003e as standard.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eCan optional fan kits be installed?\u003c\/h3\u003e\n\u003cp\u003eYes. The Essential Series™ is \u003cstrong\u003efan-ready\u003c\/strong\u003e and supports optional filtered fan ventilation whenever additional airflow is required.\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003eCan STURDX customize this enclosure?\u003c\/h3\u003e\n\u003cp\u003eAbsolutely. STURDX offers custom dimensions, \u003cstrong\u003e304 or 316 stainless steel construction\u003c\/strong\u003e, OEM branding, cable entry modifications, electrical integration, gland plates, rack accessories, wall or pole mounting solutions, and project-specific configurations for marine, industrial, telecommunications, utility, transportation, and critical infrastructure applications.\u003c\/p\u003e"}

Specification	Value
Series	STURDX Essential Series™
SKU	STX-ES-12U450-SS
Rack Height	12U
Rack Standard	19-inch EIA-310
External Dimensions	23.6" × 17.7" (600 × 450 mm)
Material	304 Stainless Steel (316 Stainless Steel Available Upon Request)
Construction	Single-Wall Construction
Protection Rating	IP66
NEMA	Suitable for NEMA 4X Applications
Cooling	Fan Ready
Mounting Rails	Four Adjustable Rails Included
DIN Rail	Included
Cable Glands	IP68 Rated Included (316 Stainless Steel Available Upon Request)
Cable Entry	Bottom Knockouts
Doors	Lockable Front Door
Wall Mount	Heavy-Duty Wall Mount Bracket Included
Pole Mount	Optional Heavy-Duty Pole Mount Bracket Available
Plinth	Included
Grounding	Included

STURDX Essential Series™ 12U IP66 Weatherproof Stainless Steel Outdoor Network Cabinet | 24" × 18" (600 × 450 mm) | 19-Inch Rack Enclosure

Product Overview

Technical Specifications

Standard Features

Designed for Marine and Corrosive Environments

Product Description

Typical Applications

Frequently Asked Questions

Why choose a 12U stainless steel outdoor cabinet?

Is this enclosure suitable for marine and offshore installations?

Does this cabinet include a rear door?

Can this cabinet be wall mounted?

Is pole mounting available?

Is a floor plinth included?

Can optional fan kits be installed?

Can STURDX customize this enclosure?
