20U Outdoor Network Cabinet – IP66 Rated with Advanced Cooling Options (Multiple Configurations)
PRODUCT OVERVIEW
The 20U Outdoor Network Cabinet is designed for large-scale outdoor deployments where maximum capacity, advanced thermal management, and long-term reliability are essential. Built for telecom infrastructure, battery systems, industrial automation, and high-power networking applications, this enclosure provides a complete outdoor solution combining IP66 weatherproof protection with integrated climate control systems.
Compared to smaller cabinets, the 20U platform offers significantly more internal space, allowing installation of high-density equipment, improved cable management, and proper airflow separation. It is specifically engineered for applications where heat load is high and environmental conditions are demanding, ensuring stable operation in real-world field environments. With multiple configurations available, including integrated air conditioning systems and large-format insulated double-wall designs, this cabinet provides the flexibility required for complex outdoor infrastructure projects.
You can find the air conditioning model that best suits your needs under the “Air Conditioners” page in the Products section. If you cannot find what you are looking for, please do not hesitate to contact us.
CUSTOM MANUFACTURING
If standard configurations do not meet your project requirements, custom production is available.
Options include:
- Custom dimensions and layouts
- Custom colors
- Stainless steel or aluminum construction
- Additional rear access, cutouts and integrations
Typical lead time: 4–6 weeks
CONFIGURATION OPTIONS
Please select the appropriate option from the dropdown menu based on your thermal load and infrastructure requirements.
A/C units can be installed on both IP55 and IP66 cabinets. All cabinets with fans are technically rated around IP55, since they require openings for airflow. IP66 enclosures, on the other hand, are completely sealed and are best used with air conditioning or for equipment that does not generate heat.
Unless you are operating in very harsh environments -such as cement factories, mining sites, heavy industrial facilities, or desert areas with intense dust - IP66 is generally unnecessary. For real-world outdoor applications, IP55 is more than sufficient and performs reliably under storms, heavy rain, wind, and typical environmental conditions.
STV-HC-20U600
20U Cabinet Only (Fan / Passive Cooling Ready)
This configuration includes the enclosure prepared for airflow-based cooling or external cooling integration.
It is suitable for:
- Low to moderate heat load systems
- Installations with external cooling solutions
- Budget-focused deployments
The cabinet is fully IP55 and IP66-rated, ensuring protection against dust, heavy rain, and direct water exposure.
OPTION 2: 20U Cabinet with Air Conditioning 300W / 600W / 2000W (110V AC & 48V DC)
This configuration includes integrated air conditioning options available in 300W, 600W and 2000W capacities, with both 110V AC and 48V DC power supply options.
Depending on the selected model:
Our air conditioners are available in a wide range of capacities and features, with models ranging from 1,000 BTU to 19,000 BTU. Options include cooling-only units, as well as models with additional heating and dehumidification functions. Remote access features such as Ethernet or RS485 connectivity are also available.
You can find the model that best suits your needs under the “Air Conditioners” page in the Products section. If you cannot find what you are looking for, please do not hesitate to contact us.
Compatible A/C Units (20U Cabinets)
STV-AN01 (1024 BTU 110V)
STV-AN02 (2050 BTU 110V)
STV-AN08 (8000 BTU 110V)
STV-MCA600AC (2050 BTU 110V)
STV-MCA600ACHD (2050 BTU 110V)
STV-BPD300ACHD (1024 BTU 48V DC)
STV-BPD600ACHD (2050 BTU 48V DC)
STV-MCA2000AC (8000 BTU 110V)
STV-MCA2000ACHD (8000 BTU 110V)
STV-BPD2000ACHD (8000 BTU 48V)
Air conditioning units are typically installed on the front door of the cabinets unless otherwise specified. The MCA2000 and BPD2000 models, however, are designed for mounting on the rear wall of 20U cabinets.
Link to the a/c units:
https://www.serverrackcabinets.com/collections/fans-ac-units
This configuration is ideal for:
- Telecom equipment
- Networking systems
- Medium heat-generating applications
It provides controlled temperature and humidity, ensuring stable operation throughout the year.
ADDITIONAL CONFIGURATIONS (INSULATED DOUBLE-WALL & REAR ACCESS)
The 20U cabinet is also available in large-format insulated double-wall configurations with rear access, designed for high-capacity and mission-critical installations.
Available sizes include:
- 24” x 32” (600 x 800 mm)
- 32” x 32” (800 x 800 mm)
- 32” x 39” (800 x 1000 mm)
- 39" x 39" (1000 x 1000 mm)
These configurations provide:
- Insulated double-wall construction for thermal protection
- Rear access door for easier maintenance and service
- Increased internal volume for batteries and large equipment
- Compatibility with high-capacity A/C systems
- Improved structural strength
These are strongly recommended for battery systems and high-heat applications.
TECHNICAL SPECIFICATIONS
The cabinet is constructed from galvanized steel with an outdoor powder-coated finish for corrosion resistance.
- Rack Capacity: 20U (19” standard)
- Width: 24” (600 mm) standard, larger options available
- Depth: 24” (600 mm) standard, extended options available
- Height: approximately 40–44” depending on configuration
- Protection Rating: IP55 and IP66
- Cooling: Fan, heat exchanger, and integrated A/C compatible
- Mounting: Floor-standing / pad-mount
- Locking System: Industrial-grade secure lock
WEATHERPROOF PROTECTION
All configurations with A/C are IP66-rated, providing:
- Full protection against dust
- Resistance against heavy rain and direct water exposure such as water jets
This ensures reliable operation in outdoor environments including telecom infrastructure, industrial sites, and exposed installations.
ADVANCED THERMAL MANAGEMENT
The 20U platform is designed for full thermal control, supporting:
- Integrated A/C systems (300W,600W, 2000W)
- Heating functions
- Dehumidifier systems
- Remote Access
- Airflow and ventilation solutions
This allows precise environmental control, preventing overheating, condensation, and equipment failure.
POWER OPTIONS FOR A/C SYSTEMS
The integrated air conditioning systems are available in both 110V AC and 48V DC configurations, allowing seamless integration with different power infrastructures and deployment scenarios.
110V AC A/C Units are ideal for standard grid-powered installations where reliable utility power is available. These units provide stable cooling performance and are commonly used in telecom sites, industrial facilities, and urban infrastructure.
48V DC A/C Units are specifically designed for telecom and off-grid applications where DC power systems are used. These are fully compatible with battery-based systems and renewable energy setups, making them suitable for remote sites, solar-powered installations, and telecom backup systems.
Offering both AC and DC-powered cooling solutions ensures flexibility in system design and allows the cabinet to be deployed across a wide range of environments without additional power conversion requirements.
Selecting the correct power type for your cooling system is critical for long-term efficiency and system reliability. In telecom and energy infrastructure projects, 48V DC solutions eliminate conversion losses and improve system integration, while 110V AC systems provide straightforward deployment in grid-connected environments. This flexibility positions the 16U cabinet as a complete infrastructure solution rather than a standard enclosure.
WHAT’S INCLUDED
Each cabinet is delivered fully assembled and ready for installation. Depending on configuration, the package includes:
- Outdoor cabinet enclosure
- Lockable sealed front door
- Internal 19” rack rails
- Cable entry points
- Mounting base
- Wall Mount Brackets
- Pre-configured airflow system
Optional:
- Fan modules
- Power distribution units
- Shelves
- Integrated A/C unit
- Monitoring systems
APPLICATIONS
- Telecom infrastructure and base stations
- Battery energy storage systems
- Industrial control systems
- Edge computing and outdoor servers
- High-power network installations
COMPETITIVE POSITIONING
Compared to others, this solution provides integrated cooling flexibility, faster availability, and simplified configuration without long lead times.
- In stock and ready to ship
- Ships from Texas
- Reduced lead times
- Custom builds in 4–6 weeks
Select the appropriate configuration from the dropdown menu based on your cooling requirements and equipment load.
For custom configurations or system design support, contact our team to receive a solution tailored to your project.
